Specifications
Circuitry: SPDT
Power Rating: 12A 125/250VAC (UL, CSA); 10(1)A 250VAC~µT85 (VDE, D, S, N, FI)
Contact Resistance: 30 milliohms max. @ initial
Insulation Resistance: 500 megaohms min. @ 500VDC
Dielectric Strength: 2,000VAC for 1 minute
Electrical Life: 10,000 operations
Terminal: right-angle PCB pins
Operation Force: 400+100 grams
Actuator Travel: 5mm
Weight: 4.2 grams
Operating Temperature: -00 to +80 Celsius
Safety Standard Approval: CSA(LR77849-23), UL(E148157), DEMKO(DK99-00024), FIMKO(FI12441), NEMKO(P98102790), SEMKO(9901082/01), VDE(118284)
RoHS Compliant: yes
Manufacture: Solteam Electronics
